Agilent Technologies 1290 - Replacing the Seal Wash Pump

1290 Infinity Quaternary Pump User Manual 143
Maintenance
9
Replacing the Seal Wash Pump
Replacing the Seal Wash Pump
When In case of wear of the seal wash pump
Parts required # p/n Description
1 5067-4793 Peristaltic Pump with Fixation Springs
Preparations Remove the flow connections from and to the seal wash pump.
1 For removing the seal wash pump, press the clips (1) and
pull the pump to the front (2).
2 Insert the pump clips to the holes in the module housing.
2
1
1
