Agilent Technologies 1290 - Replacing Wash Seal and Gasket

1290 Infinity Quaternary Pump User Manual 171
Maintenance
9
Replacing Wash Seal and Gasket
Replacing Wash Seal and Gasket
Tools required p/n Description
01018-23702 Insert tool
Parts required p/n Description
0905-1718 Wash Seal PE
5062-2484 Gasket, seal wash (pack of 6)
1 Use the steel side of the insert tool for removing the
wash seal.
2 Use the soft plastic side of the insert tool for inserting the
wash seal into the support ring. Wet the wash seal with
isopropanol or another suitable solvent before insertion.
Wash seal
>chZgiidda
LVh]hZVa
Hjeedgig^c\
Heg^c\
HZVa
