1290 Infinity Quaternary Pump User Manual 263
LAN Configuration
13
Initialization Mode Selection
Initialization Mode Selection
The following initialization (init) modes are selectable:
Bootp
When the initialization mode Bootp is selected, the module tries to
download the parameters from a Bootp Server. The parameters obtained
become the active parameters immediately. They are not stored to the
non- volatile memory of the module. Therefore, the parameters are lost
with the next power cycle of the module.
Figure 39 Bootp (Principle)
Tabl e 14 Initialization Mode Switches
SW 6SW 7SW 8Init Mode
OFF OFF OFF Bootp
OFF OFF ON Bootp & Store
OFF ON OFF Using Stored
OFF ON ON Using Default
ON OFF OFF
DHCP
1
1
Requires firmware B.06.40 or above. Modules without LAN on board, see G1369C LAN Interface Card
7ddie
HZgkZg
6Xi^kZ
EVgVbZiZg
