142 1290 Infinity Quaternary Pump User Manual
9 Maintenance
Installing the Jet Weaver
3
Insert the Jet Weaver to the opening in the front panel (1)
and push it down (2).
4 Mount both capillary connections to the Jet Weaver
observing the correct orientation.
5 Connect the inlet capillary of the Jet Weaver to port 2 of
the Multi Purpose Valve. Connect the outlet capillary to
port 1.
6 Configure the Jet Weaver as mixer in the user interface,
see “Instrument Configuration” on page 56.
