1290 Infinity Quaternary Pump User Manual
151
Maintenance
9
Releasing a Stuck Inlet Valve
7
Push the syring
e for flushing the inlet
valve and pump
head.
8
Restore original conn
ections. Flush the system
for
several minutes.
150
152
