162 1290 Infinity Quaternary Pump User Manual
9 Maintenance
Disassembling the Primary Pump Head
7
Use the steel side of the insert tool for removing the
pump seal from the pump chamber housing.
Do not use the pump piston for that purpose, as this
can break it!
8
To flush out particles from the pump head, use
pressurized air ((1), (2) and (3)).
Pump head parts in contact with the piston seal need
to be cleaned properly in order to get a smooth surface
and a tight connection.
