36 1290 Infinity Quaternary Pump User Manual
3 Installing the Module
Optimizing the Stack Configuration
Figure 9 Recommended stack configuration for 1290 Infinity with quaternary pump
(rear view)
CAN Bus cable
Analog detector signal
(optional)
CAN Bus cable
to Instant Pilot
LAN to control software
AC Power
