38 1290 Infinity Quaternary Pump User Manual
3 Installing the Module
Optimizing the Stack Configuration
Figure 11 Recommended two stack configuration for 1290 Infinity with quaternary pump
(rear view)
LAN to control software
CAN Bus cable to
Instant Pilot
Analog detector signal
(optional)
Thermo cable
(optional)
CAN Bus cable
AC Power
