Troubleshooting 5
16900A, 16902A, and 16903A Service Guide 37
Figure 10 16903A Application Troubleshooting Flowchart
5
Reinstall the logic analyzer application.
Replace the MIB board.
Replace the PCI bridge board.
Check all cables to front panel assembly .
Check all cables to CPU motherboard.
Check all cables to IO board.
Reseat as necessary.
1
1
Try each of the following steps in order.
Return to between each.
A
B
C
D
To Next Page
