78 16900A, 16902A, and 16903A Service Guide

6 Replacing Assemblies

3 Using Torx T20 and T10 screwdrivers, remove the 4

screws that secure the 700 Watt power supply to the

chassis.

4 Using a Torx T20 screwdriver, remove the 4 screws that

secure the 500 Watt power supply to the chassis.

16903A power supply

1 Perform previous procedures:

• “To prepare the instrument for disassembly" on

page 48

• “To remove and replace the cover" on page 52

2 Disconnect the following cables:

• Power Cable

• Sense Cable

• 24- Position Cable

• 22- Position Cable

• 16- Position Cable

3 Using Torx T20 and T10 screwdrivers, remove the 4

screws that secure the power supply to the chassis.

T20

Screws (2)

700 Watt

Power

Supply

T10

Screw

(1)

T20

Screws (4)

500 Watt

Power

Supply

Sense

Cable

12-Position

Cable

12-Position

Cable

Sense

Cable

Power

Cable

Power

Cable

T10

Screw

(1)
