Agilent 16900A, 16902A, and 16903A Logic Analysis System
Service Guide
Agilent Technologies
6
Replacing Assemblies
16900-Series Disassembly/Assembly 46
To prepare the instrument for disassembly 48
To remove and replace optional modules or filler panels 50
To remove and replace the cover 52
To remove and replace the CPU tray 53
To remove and replace the PCI board 56
To remove and replace optional interface cards 58
To remove and replace the I/O board 60
To remove and replace the hard disk drive 62
To remove and replace the motherboard 63
To remove and replace the front panel assembly 64
To remove and replace the CD-ROM Drive 65
To remove and replace the touch-screen controller
board 66
T
o remove and replace the backlight inverter board 68
To remove and replace the front panel interface board 69
To remove and replace the LCD bracket assembly 71
T
o remove and replace the touch-screen/display assembly 72
To remove and replace the keypad and keypa
d board 74
To remove and replace the On|Off key 76
To remove and replace the power supplies 77
To remove and replace the card cage and fans 80
To remove and replace the line filter assembly 82
To remove and replace the module interface board
83
Returning Assemblies 85
NOTE
Part drawings in this chapter are representative. The actual parts may look
different.
