Agilent Technologies 16900A

Replacing Assemblies 6
16900A, 16902A, and 16903A Service Guide 55
3 Remove 9 screws from the back of the CPU tray using a
Torx T10 screwdriver.
4 Slide the tray out being careful not to catch the loose
cables on anything.
5 Reverse this procedure to install the CPU tray.
CPU power
Hard drive power
Front panel reset
CD ROM cable
PCI cable
Module
Interface
Board
T10 screws (9)
