Agilent Technologies 16900A

84 16900A, 16902A, and 16903A Service Guide
6 Replacing Assemblies
4 Using a Torx T10 screwdriver, remove the 6 screws
securing the front strut to the chassis.
5 Using a Torx T10 screwdriver, remove the 8 screws
securing the module interface board to the front strut.
Front
Strut
T10 Screws (4)
Module
Interface
Board
T10 Screw
T10 Screws (2)
T10 Screws (8)
Chassis
