Agilent Technologies 16900A

96 16900A, 16902A, and 16903A Service Guide
7 Replaceable Parts
MP35 16900-04102 1 Duct - for 500 W supply
MP36 0950-4462 1 Power supply - 500 W 4 outputs
MP37 16900-68501 1 Fan
MP38 16900-66501 1 PCI board
MP39 16900-01210 1 CPU reset bracket
MP40 0960-2252 1 Motherboard Micro-ATX 1 GHz CPU
MP41 86122-60020 1 Rear power on/off switch
MP42 16900-66503 1 I/O board
MP43 0950-4590 1 Hard drive 80 GB ATA Ultra-100
MP44 16900-64101 1 Hard drive plate assembly
MP45 1600-1707 1 Short ISA slot cover
MP46 1400-2120 1-2 ISA slot cover
MP47 16700-40501 0-6 Module Filler panel
W3 16900-61603 1 Cable - CDR (MIB/CPU)
W8 16700-61602 1 Power supply cable - for 500 W and 700 W supplies
W9 16900-61609 1 Line filter assembly
W10 E5861A 1 Multiframe Pro cable
W11 16900-61611 1 Cable - touch screen RS-232
W12 16900-61605 1 CPU reset cable
W13 16600-61611 1 Cable - hard drive power
W14 16900-61601 1 Cable - hard drive
W15 16903-61600 1 Motherboard power cable
W16 16900-61610 1 Cable - rear power on/off
W17 16900-61606 1 Cable - CD/ROM
W19 16700-61603 1 Cable - sense
Table 4 Replaceable parts for the 16900A and 16902A frames (continued)
Ref.
Des.
Agilent Technologies Part
Number Qty Description
