Agilent Technologies 34410A Service Guide

34410A/11A/L4411A Service Guide 27
Specifications 1
Operating Characteristics - Maximum readings/second
Additional 34411A Specifications
Resolution See table on page 20
Overall Bandwidth, DCV and DCI 15 kHz typical @ 20 µs aperture (–3 dB)
Triggering Pre or Post, Internal or External, Positive or Negative
Timebase Resolution 19.9524 µs, 0.01% accuracy
Trigger Jitter 2 µs(p-p), 20 µs(p-p) when pre-triggered
External Trigger Latency < 3 µs
Internal Trigger Level Accuracy 1% of range
Spurious-Free Dynamic Range and SNDR
[1] Maximum rate for DCV, DCI, and resistance functions (0 settling delay, autozero off, manual range)
[2] 10 V range specifications are valid for signals 2 V(p-p) < x(t) < 16 V(p-p)
[3] 100 µA range specifications are valid for signals 28.8 µA(p-p) < x(t) < 200 µA(p-p)
Function[1] Digits
4.5 5.5 6.5
DCV
2-wire Ω
DCI
ACV
ACI
Frequency
Period
50k
50k
50k
500
500
450
450
10k
10k
10k
500
150
90
90
1k
1k
1k
150
150
10
10
Function Range Spurious-Free
Dynamic Range
Signal to Noise
Distortion Ratio (SNDR)
DCV 100.0000 mV
1.000000 V
10.00000 V
[2]
100.0000 V
1000.000 V
–55 dB
–75 dB
–70 dB
–75 dB
–60 dB
40 dB
60 dB
65 dB
60 dB
55 dB
DCI 100.0000 µA
[3]
1.000000 mA
10.00000 mA
100.0000 mA
1.000000 A
3.00000 A
–50 dB
–65 dB
–45 dB
–65 dB
–65 dB
–70 dB
38 dB
50 dB
38 dB
50 dB
55 dB
55 dB

Agilent Technologies 34410A Specifications

General

Brand	Agilent Technologies
Model	34410A
Category	Multimeter
Language	English
