72 34410A/11A/L4411A Service Guide
3 Calibration Procedures
Optional AC Voltage Performance Verification Tests
Configuration: AC Volts (CONFigure[:VOLTage]:AC)
LF 3 HZ:SLOW ([SENSe:]VOLTage:AC:BANDwidth 3)
1 Make sure you have read “Test Considerations” on page 63.
2 Connect the calibrator to the input terminals.
a For the 34410A/11A use the front panel input terminals and select
the Front input terminals with the Front/Rear switch.
3 Set the AC Volts function and the 3 Hz input filter. With the slow filter
selected, each measurement takes 2.5 seconds to complete.
4 Select each range in the order shown below. Provide the indicated input
voltage and frequency. Compare measurement results to the appropriate
test limits shown in the table. (Be certain to allow for appropriate
source settling.)
Input Error from Nominal
Vrms Frequency Range 24 hour 90 day 1 year
1 V 10 Hz 1 V ± 430 µV ± 830 µV ± 930 µV
1 V 1 kHz 1 V ± 400 µV ± 800 µV ± 900 µV
1 V 20 kHz 1 V ± 400 µV ± 800 µV ± 900 µV
1 V 50 kHz 1 V ± 900 µV ± 1.4 mV ± 1.5 mV
1 V 100 kHz 1 V ± 2.8 mV ± 3.8 mV ± 4.8 mV
1 V 300 kHz 1 V ± 15 mV ± 17 mV ± 17 mV
10 V 1 kHz 10 V ± 4 mV ± 8 mV ± 9 mV
1 V 1 kHz 10 V ± 2.2 mV ± 3.5 mV ± 3.6 mV
0.1 V 1 kHz 10 V ± 2.02 mV ± 3.05 mV ± 3.06 mV
