74 34410A/11A/L4411A Service Guide
3 Calibration Procedures
Optional Capacitance Performance Verification Tests
Configuration: Capacitance
CONFigure:CAPacitance
1 Make sure you have read “Test Considerations” on page 63.
2 Set the Capacitance function.
3 Connect the calibrator to the input terminals.
a For the 34410A/11A use the front panel input terminals and select
the Front input terminals with the Front/Rear switch.
4 Select each range in the order shown below. Provide the indicated
input. Compare measurement results to the appropriate test limits
shown in the table. (Be certain to allow for appropriate source settling.)
Input
Error from
Nominal
Capacitance Range 1 year
1 μF1 μF ± 0.005 μF
1 μF10 μF ± 0.014 μF
