34410A/11A/L4411A Service Guide 73
Calibration Procedures 3
Optional AC Current Performance Verification Tests
Configuration: AC Current (CONFigure:CURRent:AC)
LF 3 HZ:SLOW ([SENSe:]CURRent:AC:BANDwidth 3)
1 Make sure you have read “Test Considerations” on page 63
2 Connect the calibrator to the input terminals.
a For the 34410A/11A use the front panel input terminals and select
the Front input terminals with the Front/Rear switch.
3 Set the AC Current function and the 3 Hz input filter. With the slow
filter selected, each measurement takes 2.5 seconds to complete.
4 Select each range in the order shown below. Provide the indicated input
voltage and frequency. Compare measurement results to the appropriate
test limits shown in the table. (Be certain to allow for appropriate
source settling.)
Input Error from Nominal
Current, rms Frequency Range 24 hour 90 day 1 year
1 mA 10 Hz 1 mA ± 1.4 μA ± 1.4 μA ± 1.4 μA
1 mA 1 kHz 1 mA ± 1.4 μA ± 1.4 μA ± 1.4 μA
1 mA 5 kHz 1 mA ± 1.4 μA ± 1.4 μA ± 1.4 μA
1 mA 10 kHz 1 mA ± 2.4 μA ± 2.4 μA ± 2.4 μA
100 mA 1 kHz 100 mA ± 140 μA ± 140 μA ± 140 μA
10 mA 1 kHz 100 mA ± 50 μA ± 50 μA ± 50 μA
1 mA 1 kHz 100 mA ± 41 μA ± 41 μA ± 41 μA
