28 34410A/11A/L4411A Service Guide
1 Specifications
Measurement and System Speeds
DMM Measurements Speeds
[1] Typical. Display off, ½ scale input signal, immediate trigger, trigger delay 0, autozero off,
autorange off, no math, 60 Hz line, null off, sample count 1, trig count 1, one interface enabled.
[2] 0.001 PLC applies to 34411A/L4411A only.
Direct I/O Measurements
[1]
Single Reading – Measure and I/O Time
Measurement
Into Memory
(Readings/Sec)
(VM Complete)
Function Resolution
(NPLC)
GPIB
Sec
USB 2.0
Sec
LAN (VXI-11)
Sec
LAN (Sockets)
Sec
DCV (10 V Range) 0.001
[2]
0.0026 0.0029 0.0046 0.0032 50000
0.006 0.0026 0.0029 0.0046 0.0032 10000
0.06 0.0031 0.0032 0.0047 0.0040 1000
1 0.0190 0.0190 0.0200 0.0190 60
ACV (10 V Range) Slow Filter 0.0100 0.0100 0.0100 0.0100 50
Medium Filter 0.0100 0.0100 0.0100 0.0100 150
Fast Filter 0.0100 0.0100 0.0100 0.0100 500
2–Wire Ω (10 kΩ Range) 0.001
[2]
0.0026 0.0029 0.0046 0.0032 50000
0.006 0.0026 0.0029 0.0046 0.0032 10000
0.06 0.0031 0.0032 0.0047 0.0040 1000
1 0.0190 0.0190 0.0200 0.0190 60
4–wire Ω (10 kΩ Range) 0.001
[2]
0.0054 0.0040 0.0045 0.0056 1500
0.006 0.0054 0.0040 0.0045 0.0056 1200
0.06 0.0074 0.0078 0.0078 0.0074 380
1 0.0390 0.0390 0.0390 0.0390 30
Frequency
1 KHz, 10 V Range
Fast Filter
1 ms Gate 0.0100 0.0100 0.0100 0.0100 500
10 mS Gate 0.0200 0.0200 0.0200 0.0200 80
100 mS Gate 0.1150 0.1150 0.1130 0.1130 10
1 S Gate 1.0200 1.0200 1.0200 1.0200 1
Capacitance
(100 nF Range)
0.0820 0.0820 0.0820 0.0820 11
