Agilent 5110/5100 ICP-OES Service Manual Agilent Restricted 241
8Support Parts
Left side RF box/ pre optics
5 Assy Radial Motor Scan G8010-67302 Radial Scan motor
6 Assy PCA ICP SSRF Filters G8010-65207 *See below, new cover may be required
NS Enclosure RF Filter board G8010-60278 Required if replacing Rev A SSRF Filter on Pre
AU1442xxxx instruments
7 Assy Cable ICP RF control G8010-60802
8 Fiber Optic Work Coil Current Sensor G8010-60803
9 Assy PCA Opto Sensor G8010-65208 Radial and Beam Selector Home Sensor
10 Seal Foam Enclosure G8010-60607
11 Washer-Flat 5.3mm-ID 10mm-OD 1m G8010-60608
12 Nut M 5 HEX 1510110200
13 Screw Adjusting 1510152000
14 Fitting Straight Male 1/8-6mm Tube G8010-60609 Plasma on sensor port
15 Fitting Elbow M/F G1/8 4mm Tube G8010-60611 For use with Snout and Cone purge connections
Item Description Part Number Remark
