Agilent 5110/5100 ICP-OES Service Manual Agilent Restricted 283
10 Installation Guide (5110 ICP-OES)
Instrument performance tests
The Calibrationdetaillog.txt file is appended with the new calibration results every time a
wavelength calibration is performed. It is highly recommended that the Poly Boost purge be on
when performing a wavelength calibration.
If you do not intend to measure wavelengths under 190 nm you may wish to turn the Poly boost
purge off.
Instrument performance tests
The installation performance tests provided in this section are identical to those used at the
factory. The torch, spraychamber and nebulizer that were used in final test are shipped with the
instrument. This allows comparison of analytical performance at installation to analytical
performance at the factory.
Sample Introduction
A multi-element test solution has been chosen which provides a selection of wavelengths (both
visible and ultraviolet) including hard and soft atomic and ionic lines.
Sample/standard solution
This multi-element test solution includes the elements required for all installation tests, and is
the same as used for the Wavelength Calibration. The Standard/sample solution should be
made from pure distilled, de-ionized water with 1% analytical reagent grade nitric acid (HNO
3
).
SVDV/VDV RV
Spraychamber Glass Double pass Spraychamber Glass Double pass Spraychamber
Nebulizer Glass Sea spray nebulizer with U Fit sample
capillary
Glass Sea spray nebulizer with U fit sample
capillary
Torch Easy fit bonded torch with 1.8mm injector Easy fit bonded torch with 1.4mm injector
Pump Tubes White/white and Blue/Blue White/white and Blue/Blue
Element Concentration (ppm)
Al 5
As 5
Ba 5
Cd 5
Co 5
Cr 5
Cu 5
K 50
Mn 5
Mo 5
Ni 5
