28 Agilent Restricted Agilent 5110/5100 ICP-OES Service Manual
3 General Information
Instrument layout
Instrument layout
The following pictures outline the location of components within the 5110 instrument.
Air flow sensor
Chimney
Control Electronics and
Camera access
Pre optics and Beam
combiner access
Water Module access
Water Cooling inlet and
outlet
Water filter
Gas filter
Gas Control access, argon Ethernet connection and accessory ports
RF Oscillator access
