62 Agilent Restricted Agilent 5110/5100 ICP-OES Service Manual
4 Removal/ Installation, Replacement and Adjustment
Tools and Supplies for 5110 instrument
Tools and Supplies for 5110 instrument
Tool Part Number Where used
Safety glasses
Protective laboratory gloves
Paper towels
Laboratory tissues
Plastic tray
Items in bold required for installation
T10 TORX Driver 5182-3466 Top Covers, Power socket, Torch interlock
T20 TORX Driver 5182-3465 Covers, General
T10 TORX Angle Wrench 8710-2140 General
T20 TORX Angle Wrench 8710-1807 Inside Torch compartment
Hex “T” Wrench (2mm) x 2 7211168000 Camera Rotation
Hex Wrench (3mm) 7210020800 Camera rotation securing screws
Hex Wrench (4mm) 8710-0641 (Set) Torch Door, Gas purge fittings
Hex Wrench (5mm) 8710-0641 (Set) Gas Purge option, Torch loader
Hex Wrench (3/16 in) Alt Torx 30 Camera rotation access holes
Hex Wrench (7/64 in) K1003-00147 AVS Valve disassembly
1 point Phillips Screwdriver Peristaltic pump, Radial window
1 point Pozidrive Screwdriver 8710-0899 Polychromator screws
2 point Pozidrive Screwdriver 8710-0900 Polychromator screws
Flat blade Screwdriver (small) 7211168200 Torch disassembly
Hex nut driver (5BA) Control board accessory connectors
Hex nut driver (7mm) RF Door interlock, Camera removal
Hex nut driver (8mm) “T” handle 7210031100 Camera water fittings, Pre optics mirrors, Argon
ratio adjustment
Ratchet Wrench (1/2 in drive) For wrench sockets
Socket wrench (11mm) Polychromator mirror removal
Socket wrench (18mm) Polychromator mounting bolts
Wrench open ended (5.5mm) Pre optics mirror adjust
Wrench open ended (7mm) Camera water fitting
Wrench open ended (12mm) 8710-1841 Packing pallet
Wrench open ended (17mm) Water filter
Wrench open ended (26mm) Instrument water compression fittings
Wrench open ended (1/2 in) 8720-0025 Work Coil
Wrench open ended (9/16 in) 8720-0025 Swagelok water fittings
Wrench open ended (5/8 in) Current sense (coil)
