Maintenance
112 Agilent 55B AA Spectrometer User’s Guide
Figure 70.
Screw the drain tube into the nebulizer block
2 Lower the drain tube into the trap, ensuring that the float drops into the space
between the two ribs that are opposite the two vent nipples – see Figure 71
below.
Figure 71. Lower the drain tube and float into the trap
3 Push the trap home and then twist it 1/4 turn clockwise to lock it into position
- see Figure 72 below.
Figure 72.
Lock the trap into position
