5 General Maintenance
5975/5977 Series MSD Operating Manual 145
Figure 45. Disassembling the EI XTR source
Table 19 Parts list for EI XTR source (Figure 45)
Item Description Part number
1 Setscrews G3870-20446
2 Screws G3870-20021
3 Source body G3870-20440
4 Extractor lens G3870-20444
5 Extractor lens insulator G3870-20445
6 Filaments G7005-60061
7 Spring washer 3050-1301
7 Flat washer 3050-0982
