4 Operating in EI Mode
5975/5977 Series MSD Operating Manual 89
Table 9 MS Parameters menu
Action Description
High Vacuum Pressure Only with Micro-Ion vacuum gauge installed.
Turbo Pump Speed Displays the turbo pump speed.
Foreline Pressure Displays the foreline pressure.
MSD Fault Status Reports a summary fault status code (number) in ‘dec’ (decimal) and
‘hex’ (hexadecimal) format covering all possible fault combinations.
Ion Source Temp,
o
C Displays and sets the ion source temperature.
Mass Filter Temp,
o
C Displays and sets the mass filter temperature.
CI Reagent Displays CI reagent gas and flow rate (if installed).
MS parameters cannot be set from the LCP while an online OpenLAB CDS
session is connected to the MSD.
Table 10 Network menu
Action Description
MSD IP via BootP Displays the IP address for the MSD.
Gateway IP Address Displays the gateway IP address for the MSD.
Subnet Mask Displays the subnet mask for the MSD.
ChemStation IP Displays the IP address for the
OpenLAB CDS PC.
GC IP Address Displays the IP address for the GC.
Ping gateway Checks communication with the gateway.
Ping ChemStation Displays the IP address for the
OpenLAB CDS PC.
Ping GC Checks communication with the GC.
MS Controller MAC Displays the MAC address of the SmartCard in the MSD.
To Next Page
