Menu Map with SCPI Commands
Menu Map for 8712ET/ES and 8714ET/ES
Table 10-11 CAL, Test Set Cal Functions, 8712ET/ES and 8714ET/ES
1. For use with multiport test sets only.
2. You select the number of test set ports, and a guided calibration procedure begins.
3. For 8712ES and 8714ES analyzers only.
KEYSTROKES SCPI COMMAND
CAL, Test Set Cal
1
SENS[1|2]:CORR:TESTSET;*WAI
Create “TSET_CAL”
2
SENS[1|2]:CORR:COLL:METHOD TEST;
XX Ports SENS[1|2]:CORR:COLL:PORTS
<2|4|6|8|10|12>
Enh Resp 1 - Port
3
SENS[1|2]:CORR:COLL:METHOD TEST 1
2 - Port
3
SENS[1|2]:CORR:COLL:METHOD TEST 2
Measure Opens SENS[1|2]:CORR:COLL:MP:OPEN
<STAN1|STAN2|…|STAN12>;*WAI;
Measure Shorts SENS[1|2]:CORR:COLL:MP:SHORT
<STAN1|STAN2|…|STAN12>;*WAI;
Measure Loads SENS[1|2]:CORR:COLL:MP:LOAD
<STAN1|STAN2|…|STAN12>;*WAI;
Measure Thrus SENS[1|2]:CORR:COLL:MP:THRU
<STAN1|STAN2|…|STAN6>;*WAI;
All Stds Done SENS[1|2]:CORR:COLL:SAVE;*WAI;
Periodic SelfCal CAL:SELF ON
SelfCal Once CAL:SELF ONCE
SelfCal Timer CAL:SELF:TIMER <num>
SelfCal All Ports CAL:SEL0F:ALL
2-Port Cal on OFF
3
CAL:SELF:METHOD [ONEP|TWOP]*WAI
Isolation on OFF
3
SENS[1|2]:CORR:ISOL [ON|OFF]*WAI
