Programmer’s Guide 10-51
Menu Map with SCPI Commands
Menu Map for 8712ET/ES and 8714ET/ES
Table 10-21 MENU Functions, 8712ET/ES and 8714ET/ES (2 of 2)
1. Used with SRL measurements only. This softkey starts an automated SRL cable
scan.
KEYSTROKES SCPI COMMAND
MENU, (continued)
SRL Cable Scan
1
SENS[1|2]:FUNC:SRL:SCAN; *WAI
Ext Ref on OFF SENS:ROSC:SOUR [EXT|INT]; *WAI
Spur Avoid Options (menu selection only)
None DIAG:SPUR:METH NONE;*WAI
Dither DIAG:SPUR:METH DITH;*WAI
Spur Avoid DIAG:SPUR:METH AVO;*WAI
