Programmer’s Guide 11-15
SCPI Command Summary
SCPI Device Command Summary
Table 11-6 DIAGnostic (2 of 4)
SUBSYSTEM COMMANDS FORM DESCRIPTION
DIAGnostic:COMMunicate:LAN:SEND
<IP_address>,<port_num>,<string>,<
timeout>
NR1,
STRING
Instructs the analyzer to open a
socket to the specified IP
address and port number, and
send the string specified.
<timeout> is an integer <num>
in the range 0-75 specifying the
number of seconds allocated for
a successful transmission. If 0 is
specified, a minimum interval of
0.10 seconds is used. If
<timeout> is not specified, the
default interval of 75 seconds is
used.
DIAGnostic:COMMunicate:LA
N:SEND? returns 0 if the last
socket connection was
successful, and -1 if the last
socket connection failed. This
may not be the last socket
connection made by the IBASIC
program. Multiple socket
connections are possible, and
telnet sessions may be
interspersed among
programmed socket connections.
DIAGnostic:MDISplay[1|2]
:CORRection
<I_Direct|I_SRcmatch|I_TRacking
|I_Response|I_LDmatch|I_ISolation
|M_Direct|M_ISolation|M_SRcmatch
|M_TRacking|M_Response|M_LDmatch
|M_XScalar|C_Direct|C_SRcmatch
|C_RTracking|C_LDmatch
|C_TTracking|C_Isolation>
command
only
Return to measurement mode
and auto scales after viewing
calibration uncertainties.
