11-26 Programmer’s Guide
SCPI Command Summary
SCPI Device Command Summary
Table 11-9 DISPlay (7 of 7)
1. Numeric parameters may include an appropriate suffix; if no suffix is included, the
default (HZ for frequency or S for time) is assumed.
SUBSYSTEM COMMANDS FORM DESCRIPTION
DISPlay:WINDow[1|2]:TRACe
:Y[:SCALe]:PDIVision<num>
1
NR3 Specifies the height (dB or units
per division) of each vertical
division of the specified
measurement channel.
DISPlay:WINDow[1|2]:TRACe
:Y[:SCALe]:RLEVel<num>
1
NR3 Specifies the value for the Y-axis
reference position for the
specified measurement channel.
DISPlay:WINDow[1|2]:TRACe
:Y[:SCALe]:RPOSition <num>
1
NR3 Specifies the Y-axis reference
position for the specified
measurement channel.
DISPlay:WINDow[1|2|10]
:TRACe[1|2]:Y:TRACk
<OFF|PEAK|FREQ>
CHAR Selects the method for reference
offset tracking.
DISPlay:WINDow[1|2|10]
:TRACe[1|2]:Y:TRACk:FREQuency
<num>
1
NR3 Selects frequency to track with
reference tracking.
