Programmer’s Guide 11-37
SCPI Command Summary
SCPI Device Command Summary
Table 11-18 ROUTe
1. For use with multiport test sets only.
2. For use with the 8712ES and 8714ES models only.
SUBSYSTEM COMMANDS FORM DESCRIPTION
ROUTe[1|2]:REFLection:PATH
:DEFine:PORT<1|2|…|12>
NR1 Selects which port of the test set is
connected to the REFLECTION
port of the analyzer.
1
ROUTe[1|2]:TRANsmission:PATH
:DEFine: PORT <1|2|…|12>
NR1 Selects which port of the test set is
connected to the TRANSMISSION
port of the analyzer.
1
ROUTe[1|2]:PATH:DEFine
: PORT <num>,<num>
NR1 Selects which port of the analyzer
is to function as the reflection (RF
out) port and which port is to
function as the transmission (RF
in) port. Choose from 1,2
(forward), or 2,1 (reverse).
2
