Programmer’s Guide 11-49
SCPI Command Summary
SCPI Device Command Summary
Table 11-19 SENSe (12 of 16)
SUBSYSTEM COMMANDS FORM DESCRIPTION
SENSe[1|2]:FUNCtion ‘FLOC
<num>,<num>’
command
only
Specifies that the receiver will measure
the ratio of the power (fault location)
into the specified measurement channel.
For 8712ET/8714ET models—choose
1,0 (Forward A/R).
For 8712ES/8714ES models—choose
1,0 (Forward A/R), or 22, 20 (Reverse
B/R).
(For use with fault location
measurement on analyzers with Option
100 only.)
SENSe[1|2]:FUNCtion
'XFRequency:POWer <num>'
command
only
Specifies that the receiver will measure
the power into a specific detector on the
specified measurement channel.
For 8712ET/8714ET models— choose
from detectors 0 (R), 1 (A), 2 (B), 11 (Ext
X) or 12 (Ext Y).
For 8712ES/8714ES models—choose
from detectors:
0 (Forward R)
20 (Reverse R)
1 (Forward A)
21 (Reverse A)
11 (Forward Ext X)
12 (Forward Ext Y)
2 (Forward B)
22 (Reverse B)
To Next Page
