11-50 Programmer’s Guide
SCPI Command Summary
SCPI Device Command Summary
Table 11-19 SENSe (13 of 16)
SUBSYSTEM COMMANDS FORM DESCRIPTION
SENSe[1|2]:FUNCtion
'XFRequency:GDELay:RATio
<num>,<num>'
command
only
Specifies that the receiver will measure
the ratio of the power ( group delay) into
the specified measurement channel. For
8712ET/8714ET models—choose ratio
2,0 (B/R).
For 8712ES/8714ES models—choose
from ratios 2,0 (Forward B/R), or
21,20 (Reverse A/R).
SENSe[1|2]:FUNCtion
'XFRequency:POWer:RATio
<num>,<num>'
command
only
Specifies that the receiver will measure
a ratio of the power into the specified
measurement channel.
For 8712ET/8714ET models— choose
from ratios 1,0 (A/R), 2,0 (B/R), 12,0
(Ext Y/R), 11,12 (Ext X/Ext Y), or
12,11 (Ext Y/Ext X).
For 8712ES/8714ES models—choose
from ratios:
1,0 (Forward A/R)
21,20 (Reverse A/R)
2,0 (Forward B/R)
22,20 (Reverse B/R)
12,0 (Forward Ext Y/R)
11,12 (Forward Ext X/Ext Y)
12,11 (Forward Ext Y/Ext X)
