Programmer’s Guide 11-51
SCPI Command Summary
SCPI Device Command Summary
Table 11-19 SENSe (14 of 16)
1. For use with the 8712ES and 8714ES models only.
SUBSYSTEM COMMANDS FORM DESCRIPTION
SENSe[1|2]:FUNCtion
'XFRequency:S <num>,<num>'
NR1,NR1 Specifies that the receiver will measure
an s-parameter into the specified
measurement channel. The s-parameter
choices will depend on the number of
ports. For example, with a 2-port device,
choose from 1,1 (S
11
), 1,2 (S
12
), 2,2
(S
22
), or 2,1 (S
21
).
As another example, with a 12-port
device using the 87075C multiport test
set, some choices would include 1,8
(S
18
), or 12,1 (S
12
,
1
), or 7,7 (S
77
).
This command may be used in place of:
SENS[1|2]:FUNC ‘XFR:POW:RAT
and ROUT[1|2}:PATH:DEF:PORT.
If using the 87075C multiport test set,
this command may be used in place of
the two commands just listed, as well as:
ROUT[1|2]:REFL:PATH:DEF:PORT
and
OUT[1|2]:TRAN:PATH:DEF:PORT.
1
SENSe[1|2]:FUNCtion:FAULt
:CONNector [:IMMediate]
command
only
Forces a connector verification
measurement on the alternate channel.
(For use with SRL measurements on
analyzers with Option 100 only.)
To Next Page
