11-54 Programmer’s Guide
SCPI Command Summary
SCPI Device Command Summary
Table 11-20 SOURce
1. Numeric parameters may include an appropriate suffix; if no suffix is included, the
default (HZ for frequency or S for time) is assumed.
SUBSYSTEM COMMANDS FORM
DESCRIPTION
SOURce[1|2]:POWer[:LEVel]
[:IMMediate][:AMPLitude]<num>
1
NR3 Sets the RF power output from the
source.
SOURce:POWer:PRESet <num> NR3 Sets the power level that the
analyzer will always return to after
an instrument preset.
SOURce[1|2]:POWer:RANGe <char> CHAR Specifies the power sweep range.
Choose from ATTen0
|ATTen10|ATTen20|ATTen30
|ATTen40 |ATTen50|ATTen60.
SOURce[1|2]:POWer:STARt <num> NR3 Sets the power sweep start power.
SOURce[1|2]:POWer:STOP <num> NR3 Sets the power sweep stop power.
