Agilent Technologies 8922M User Manual

3-27
Verifying Performance
Agilent Technologies 8922M/S Specifications
Audio Filters
There are seven filters used in the Agilent 8922M/S.
• 50 Hz HPF
• 300 Hz HPF
• 300 Hz LPF
• 3 kHz LPF
• 15 kHz LPF
• 750 µs de-emphasis
• 1 kHz notch
Audio Detectors
The audio detectors available in the Agilent 8922M/S are:
• Pk+
• Pk-
• Pk + hold
•Pk− hold
•Pk±/2
•Pk±/2 hold
•Pk±max
•Pk±max hold
• RMS
Oscilloscope Specifications
Frequency Range (3 dB) 2 Hz to 50 kHz
Scale/Division 10 mV to 10 V in 1, 2, 5, and 10 steps
Amplitude Accuracy (20 Hz to 10 kHz)
±1.5% of reading ±0.1 division
Time/Division 10 µs to 100 ms in 1, 2, 5, and 10 steps
External Trigger Level TTL
Maximum voltage
Scope In
5 V peak
Audio In
30 V
rms
Supplemental Characteristics:
3 dB Bandwidth
Typically >100 kHz
Internal DC Offset:
≤0.1 division for ≥50 µV/div sensitivity
