3-28
Verifying Performance
Agilent Technologies 8922M/S Specifications
Remote
Programming
General
Specifications
WARNING: For continued protection against fire hazard, replace the line fuse only with the
same type and line rating (F 2.5A H, 250V for 220/240V operation or F 5.0A H,
250V for 100/120V operation). The use of other fuses or materials is prohibited.
WARNING: Shock hazard. No operator serviceable parts inside. Service by qualified
personal only.
Cleaning To clean the instrument, use a soft, clean damp cloth to clean the front panel and
covers.
GPIB IEEE Standard 488.2
Functions Implemented SH1, AH1, T6, L4, SR1, RL1, LE0, TE0, PP0, DC1, DT1, C4, C11, E2
RS-232 3 wire RJ-11 connector used for serial data in and out.
Baud Rates 300, 1200, 2400, 4800, 9600, and 19200 selectable.
Size
177H
× 426W × 574D mm
(7
× 16.75 × 23 in). (nominal)
Weight 32 kg, 70 lbs
Operating Temperature
0
° to +55°C
Storage Temperature
−40° to +70°C
Humidity
Up to 95% Relative Humidity to 40
°C
Altitude up to 4600 m (15,000 feet)
The following power requirements are for mains connected equipment, unless otherwise stated.
Power
100, 120, 220, 240 Vac, 48 to 440 Hz,
±10% of line voltage, maximum 450 VA
EMC Refer to the front section of this User’s Guide for more information
Supplemental Characteristics
Leakage
At RF Generator output levels <
−40 dBm, typical leakage is <1 µV
induced in a resonant dipole antenna 1 inch away from any surface
except the rear panel.
