4-44
Screens
Cell Control 2
29. RF Anl Ampl
Control
This field selects control of the RF analyzer’s amplitude setting field.
Choices MS TX Lev automatically sets the RF analyzer’s amplitude setting
based on the TX Level field.
Manual requires manual setting of the RF analyzer’s amplitude.
30. RR This field displays the currently established logical channel as indicated by the
Radio Resource sublayer.
• BCCH indicates that a broadcast channel is being transmitted, and the
Agilent 8922M/S is ready to receive a RACH.
• DCCH indicates that a control channel is established. The physical channel
organization depends on the Control Channel setting (see Cell Configuration
screen).
• TCH1 indicates that a traffic channel is established using the parameters from a
TCH1 setup (see TCH Parms, Cell Control screen).
• TCH2 indicates that a traffic channel is established using the parameters from a
TCH2 setup (see TCH Parms, Cell Control screen).
• None is displayed when the instrument mode is Settable (see Cell Configuration
screen).
