6-14
Connectors
Rear-Panel Connectors of the Agilent Technologies 8922M/S
6. OPT 001 REF
OUT
The option 001 reference output connector, when present, is connected to an high-
stability 10 MHz reference. Typically, it is connected to REF IN (using an Agilent
supplied short jumper cable) to get all timebase references locked to the high-
stability timebase reference. This connector can also be used as a general-purpose
output.
This output should be turned off when not in use, to reduce spurs and other
unwanted signals.
Option 001 REF OUT is turned on and off by the OPT 001 REF OUT field on the
Configure screen.
See Also
Screens: Configure Specifications REF IN
