Agilent Technologies 8922M User Manual

3-17
Verifying Performance
Agilent Technologies 8922M/S Specifications
30 dB Pulse Modulation (Agilent 8922M only)
All timeslots 30 dB higher than desired/active timeslot, to test adjacent timeslot
rejection.
AM for Level Control (Agilent 8922M Only)
For output levels ≤+1 dBm at Aux RF Out or ≤−19 dBm at RF In/Out
Supplemental Characteristics:
Input Levels TTL
Rise/Fall Time (10 to 90%)
≤5 µs
Supplemental Characteristics:
Input
Range
−1.0V to +0.6V
Impedance
600Ω nominal, DC Coupled
Sensitivity
100% AM per volt, nominal
Calibration
0 VDC input produces calibrated output from the RF Generator
Rise/Fall Time (10 to 90%)
≤10 µs
