FORMat Subsystem
ASCii - Amplitude values are in ASCII, in amplitude units, separated by
commas.
INTeger, 32 - Binary 32-bit integer values in internal units (mdBm), in a
definite length block.
REAL, 32 (or 64) - Binary 32-bit, or 64-bit, real values in amplitude units), in
a definite length block.
UINTeger, 16 - Binary 16-bit unsigned integer uncorrected ADC values, in a
definite length block.
Factory Preset
and *RST: ASCII
Table 5-2
Corrected Trace Data Types
:TRACe:DATA? <trace_name>
Data Type Result
ASCII Amplitude Units
INT,32 (fastest) Internal Units
REAL,32 Amplitude Units
REAL,64 Amplitude Units
Table 5-3
Uncorrected Trace Data Types
:TRACe:DATA? RAWTRACE
Data Type Result
INT,32 Uncorrected ADC Values
UINT,16 (fastest) Uncorrected ADC Values
