Chapter 2 81
Status Registers
Use Status Registers to Determine the State of Analyzer Events and Conditions
Bit Decimal
Value
Description
00Source Synth Unlocked: A 1 in this bit position indicates
that the synthesizer in the source (tracking generator) is
unlocked.
12Freq Ref Unlocked: A 1 in this bit position indicates that
the analyzer frequency reference is unlocked.
24Reserved: This bit is not used by the analyzer, but are for
future use with other Agilent products.
38Reserved: This bit is not used by the analyzer, but is for
future use with other Agilent products.
416Synth Unlocked: A 1 in this bit position indicates that the
analyzer synthesizer is unlocked.
532Invalid Span or BW: A 1 in this bit position indicates
an invalid span or bandwidth during frequency count.
664Reserved: This bit is not used by the analyzer, but are for
future use with other Agilent products.
7 128 Reserved: This bit is not used by the analyzer, but are for
future use with other Agilent products.
8 256 Reserved: This bit is not used by the analyzer, but are for
future use with other Agilent products.
9 512 Demodulation: A 1 in this bit position indicates an invalid
span during FM Demodulation and Listen measurements.
10 1024 Unused: This bit is always set to 0.
11 2048 Unused: This bit is always set to 0.
12 4096 Unused: This bit is always set to 0.
13 8192 Unused: This bit is always set to 0.
14 16384 Unused: This bit is always set to 0.
15 32768 Always Zero (0): This bit is always set to 0.
