90 Chapter 2
Status Registers
Use Status Registers to Determine the State of Analyzer Events and Conditions
Bit Decimal
Value
Description
01Reserved: This bit is not used by the analyzer, but is for
future use with other Agilent products.
12Reserved: This bit is not used by the analyzer, but is for
future use with other Agilent products.
24Reserved: This bit is not used by the analyzer, but is for
future use with other Agilent products.
38Data Uncalibrated Summary: This is the summary
bit for the Questionable Status Integrity Uncalibrated
Register.
416IF/ADC Over Range: The signal input level is too high,
causing the analyzer analog-to-digital converter (ADC)
range to be exceeded. This may occur with resolution
bandwidths less than or equal to 300 Hz in zero span.
5 32Reserved: This bit is not used by the analyzer, but are for
future use with other Agilent products.
6 64Reserved: This bit is not used by the analyzer, but are for
future use with other Agilent products.
7 128Reserved: This bit is not used by the analyzer, but are for
future use with other Agilent products.
8 256Reserved: This bit is not used by the analyzer, but are for
future use with other Agilent products.
9 512 Reserved: This bit is not used by the analyzer, but are for
future use with other Agilent products.
10 1024 Reserved: This bit is not used by the analyzer, but are for
future use with other Agilent products.
11 2048 Reserved: This bit is not used by the analyzer, but are for
future use with other Agilent products.
12 4096 Invalid Data: A 1 in this bit position indicates that the
present trace data does not reflect the existing analyzer
state. Trigger a new sweep and/or measurement.
13 8192 Reserved: This bit is not used by the analyzer, but is for
future use with other Agilent products.
14 16384 Reserved: This bit is not used by the analyzer, but is for
future use with other Agilent products.
15 32768 Always Zero (0): This bit is always set to 0.
