Agilent Technologies G1314B - Page 63

Agilent 1260 Infinity VWD User Manual 63
Using the Detector
4
Setting up an Analysis
The Online Plot (Figure 21 on page 63) shows both, the pump pressure
and the detector absorbance signals. Pressing Adjust the signals can be
reset to the offset value and Balance would do a balance on the
detector.
Figure 21 Online Plot Window
13 If both baselines are stable, set the Y- range for the detector signal to
100 mAU.
EjbeegZhhjgZh^\cVa
KL9VWhdgWVcXZh^\cVa
NOTE
If you start with a new UV-lamp for the first time, the lamp may show initial drift for some
time (burn-in effect).
