Agilent Technologies G7104C User Manual

1260 Infinity II Flexible Pump User Manual 79
3Using the Module
Setting up the Pump with the Instrument Control Interface
Advanced Settings
The Quaternary Pump advanced method setup parameters are in five sections:
• Minimum Stroke
• Compressibility
• Maximum Flow Gradient
• Primary Channel
• Mixer Selection
Pressure Limits Max: 800 bar
(11600 psi) for flow
rates up to 5 mL/min.
Min: any value
between 0 and the
upper pressure limit
setting.
Sets the maximum and minimum pressure limits for the pump.
•Max is the maximum pressure limit at which the pump will switch itself
off, protecting the analytical system against over-pressure.
•Min is the minimum limit at which the pump will switch itself off, for
example, if any solvent reservoir is empty, this prevents system damage
by pumping air.
Timetable See “Timetable Settings” on page 81
Advanced See “Advanced Settings” on page 79
ISET Set the ISET parameters in this dialog box. For further information on ISET,
please refer to the Online Help or to the Agilent InfinityLab LC Series Systems
with Intelligent System Emulation Technology - User Manual (p/n
G7120-90310).
Table 9 Method parameters
Parameter Limits Description
