Agilent N5181A/82A MXG Signal Generators User’s Guide 61
Using Pulse Modulation (Option UNU)
The Basic Procedure
The Basic Procedure
1. Preset the signal generator.
2. Set the carrier (RF) frequency.
3. Set the RF amplitude.
4. Configure the modulation:
a. Set the pulse source: Press Pulse > Pulse Source > selection
b. Set the parameters for the selected pulse source:
5. Turn on the modulation: Pulse Off On softkey to On.
The the PULSE annunciator lights, indicating that you enabled modulation.
6. Output the modulated signal from the signal generator: Press the front panel RF On Off key.
The RF output LED lights, indicating that the signal is transmitting from the RF output connector.
See also, “Modulating the Carrier Signal” on page 34.
Example
The following example uses the factory preset pulse source and delay.
1. Preset the signal generator.
2. Set the frequency to 2 GHz.
3. Set the amplitude to 0 dBm.
4. Set the pulse period to 100 microseconds: Press Pulse > Pulse Period > 100 > usec.
5. Set the pulse width to 24 microseconds: Press Pulse > Pulse Width > 24 > usec
6. Turn on both the pulse modulation and the RF output.
The PULSE annunciator displays and the RF output LED lights.
If the modulation does not seem to be working properly, refer to “No Modulation at the RF Output”
on page 143.
Square Free Run (default) Triggered Adjustable Doublet Trigger Doublet Gated External
Pulse Rate
Pulse Period Pulse Period
Pulse Delay Pulse Delay Pulse Delay Pulse Delay
Pulse Width Pulse Width Pulse Width Pulse Width Pulse Width
Pulse 2 Delay
Pulse 2 Width
Output: A 2 GHz, 0 dBm carrier modulated by a 24 µs pulse that has a period of 100 µs.
