59
Chapter 4: Performing a Spin
VSpin User Guide
3. Make sure that the bucket is accurately aligned with the door.
If the bucket is not aligned correctly, see “Teaching the Bucket
Position” on page 41.
4. Using the directions in “Setting the Presented Bucket” on page 55,
move the bucket that will contain the balance plate to the front and
place the balance plate on the bucket.
5. Move the bucket that will contain the sample plate to the front and
place the sample plate on the bucket.
Leave the
Bucket to present selection set for the bucket that contains
the sample plate so that the sample plate is accessible for future
spins.
6. Check your motion settings, and change them if necessary.
See “Configuring Motion Settings” on page 51.
7. Click
Start spin cycle from the Execute group box of the Control
page.
The spin cycle starts, using the settings specified.
8. To perform additional spins, replace the sample plate with another
one that is within 10 grams of the balance plate and click
Start spin
cycle
again.
00102
VSpin
Bucket
00102
Towards spindle center
00085
VSpin
bucket alignment
00085
bucket
