Specifications
Maintenance
• Clean the unit gently with a soft, dry cloth. If difficult to clean, dip a soft cloth in neutral detergent diluted with water,
wring it out well, and then clean unit.
• Use a soft, dry cloth (for use in wiping mirrors) when wiping the display.
Power PoE (IEEE802.3af Class 0 standard)
Consumption current Standby: 66 mA; Maximum: 155 mA
Communication Hands-free/touch-to-talk
(concurrent communication for calls between handsets only)
Display 7" TFT LCD display WVGA 800×480 (approx. 1.15 million pixels)
Camera 1/4-type CMOS VGA 640×480 (approx. 300,000 pixels)
LAN Ethernet (10BASE-T, 100BASE-TX), Auto MDI/MDI-X-compatible
Audio codec G.711 (u-law, A-law), G.722
Video codec H.264/AVC, Motion-JPEG
Protocol IPv4, IPv6, TCP, UDP, SIP, HTTP, HTTPS, RTSP, RTP, RTCP, IGMP, MLD, SMTP, SFTP,
DHCP, NTP, DNS
Encryption system TLS1.0, TLS1.1, TLS1.2
Packet transmission system Unicast and multicast
Number of stations in
address book
500 stations
Operating temperature 0 °C to +40 °C (+32 °F to +104 °F)
Shape Table/wall-mounted
Materials Fire-retardant resin
Color IX-MV7-HW, IX-MV7-W: White
IX-MV7-HB, IX-MV7-B: Black
Dimensions IX-MV7-HB and IX-MV7-HW: 280 mm (11") [W] × 204 mm (8-1/16") [H] × 55.5 mm (2-3/16") [D]
IX-MV7-B and IX-MV7-W: 220 mm (8-11/16") [W] × 172 mm (6-3/4") [H] × 31.5 mm (1-1/4") [D]
(excluding projection)
Weight: IX-MV7-HB and IX-MV7-HW: Approx. 1.0 kg (2.2 lbs) (approx. 1.3 kg (2.9 lbs) when used on
table)
IX-MV7-B and IX-MV7-W: Approx. 680 g (1.5 lbs) (approx. 870 g (1.97 lbs) when used on table)
Important
• Do not use chemicals such as benzene or paint thinner. You may damage the surface of the device, or cause discoloration.
