Aiphone IX-MV7-HW - Relay Output (Administrator Privileges Only)

134
Settings and Adjustments
Configure on the device.
4
Relay Output (administrator privileges only)
Configure settings related to relay output.
1. On the Settings(2/2) screen, tap [Relay Output].
• The Relay Output Settings screen is displayed.
2. Change the settings.
Important
• The four relay output methods are shown below. Redundant configuration is possible for each output terminal. If multiple
commands occur during a single relay output, the latest command will take priority.
– Function selected in
“FUNCTION (→page 135)”
– Function selected in
“OPTION RELAY CONTROL (→page 135)”
– Function selected in
“Relay Output 1 Schedule integration setting, Relay Output 2 Schedule integration setting
(→page 136)”
– CGI control
