AIRTRONICS MT-S - System Features; Whats Included; Items Required, but Not Included; System Specifications

6
MT- S
2.4GHZ FH4T RADIO SYSTEM USER'S GUIDE
TR
Telemetry System with Sanwa Synchronized Link Support
• Normal, SHR and SSR Channel Response Modes
• DualThrottleMixingwithDigandBurnforRockCrawlers
• CODEAuxiliary
• StepAuxiliary
• PointAuxiliary
• AuxiliaryMixing
• ProgrammableFailSafe
• ReceiverBatteryVoltageFailSafe
• DigitalTrimsandServoSub-Trim
• ThrottleOffset
• AdjustableThrottleTriggerPosition
• AdjustableThrottleTriggerSpringTension
• AdjustableSteeringWheelTension
• ProgrammableSwitches
• VariableRateAdjustment
• ModelNaming
• ModelSelect
• ModelClear
• SelectableModulationType
• AdjustableLCDContrast
• AdjustableKeyVolumeandTone
• ProgrammableLowVoltageAlarm
• InactivityandOverVoltageAlarms
• DigitalBatteryVoltageMonitor
• SimplifiedProgrammingMenus
• SetupWizardwithEightCarTypes
• 20ModelMemory
• TelemetryLogging
• ServoReversing
• Steering,ThrottleandBrakeDualRate
• EndPointAdjustment
• AdjustableRateControl(ARC)Adjustment
• ServoSpeedAdjustment
• Anti-LockBraking
• Lap,IntervalandDownTimers
• Total,BestandIndividualLapDisplay
• FourWheelSteeringMixing
Transmitter:
• Model:MT-S(90478)
• OutputPower:60mW
• NominalInputVoltage:4.8vto7.4v
• OperatingVoltageRange:4.0vto9.6v
• DryWeight:12.9oz(366g)
• Frequency:2.4GHzFHSS
•ModulationType:FH3,FH4T(VariesbyRegion)
Receiver:
• Model:RX-482(92082)SuperResponseSSL
• NominalInputVoltage:3.7vto7.4v
• Weight:0.25oz (7.1g)
• Dimensions:0.71x0.96x1.06in(18.2x24.4x27.1mm)
• Frequency:2.4GHzFH3/FH4TSelectableViaTransmitter
• FailSafeSupport:Yes(AllChannels)
•BatteryVoltageFailSafeLimit:3.5to5.0v(FH3)/3.5to7.4v(FH4T)
• 4-Channel2.4GHzFH4TDigitalHigh-ResponseTelemetrySystemwithAdvancedProgramming
• BacklitLCDScreenAllowsYoutoEasilyViewProgrammingOptionsandTelemetryDatainAllTypesofConditions
• High-PowerFH4TTechnologyProvidestheBestReceptionandConnectivity,GivingRacersAddedAssurance
• 4-CellDryBatteryHolderforLighterWeight-AlsoAcceptsOptionalNiMHBatteriesor2SLiPoor2SLiFeBatteryPacks
•IncludesRX-4822.4GHzFH4TSuperResponseReceiverw/SanwaSynchronizedLinkSupport
SYSTEM FEATURES
GENERAL
SYSTEM SPECIFICATIONS GENERAL
The following accessories are included with your MT-S. If an accessory is missing or if any parts appear damaged in any way,
please contact the Airtronics or Sanwa service center in your region. For more information, see the Service and Support section
on page 4. Contents may vary and are subject to change without notice.
• MT-S 2.4GHz FH4T Digital High-Response Transmitter
• RX-482(92082)SuperResponseSSLReceiver
WHAT'S INCLUDED GENERAL
• ReceiverOn/OffSwitch
• ReceiverDustBootCovers
ITEMS REQUIRED, BUT NOT INCLUDED GENERAL
Transmitter Batteries:
• Four'AA'AlkalineorNiMHcellsorone2SLiPoor2SLiFebatterypack.
Servos and ESCs:
• WerecommendusingdigitalservosandESCsthatsupportahighframeratewheneverpossible.Duetotheextremely
high frame rate of the MT-S transmitter and RX-482 Super Response SSL receiver, analog servos and many ESCs may
not be compatible when used with SHR or SSR Channel Response Modes. To prevent compatibility issues, use analog
servos only in the NOR Channel Response Mode. If your ESC does not work using the SHR Channel Response Mode, use
the NOR Channel Response Mode. Any brand and type of digital servo can be used with NOR or SHR Channel Response
Modes. Only Airtronics or Sanwa SRG series digital servos are compatible for use with the SSR Channel Response Mode.
Accessories:
• For a complete list of accessories, such as receivers, Telemetry sensors, ESCs, gyros and much more, please visit
www.airtronics.net (in North America only) or your local Airtronics or Sanwa authorized dealer. For a list of Sanwa distributors
in your region, visit www.sanwa-denshi.com/rc/distributors.html.
